Industrial battery chargers are used for charging large battery banks and also provide DC output to the load. Powertrix Control Systems offers DC power systems that use the latest 6 pulse IGBT technology offering high input PF and greater efficiency. Float cum boost chargers ensure that the charger supplies DC load automatically. A float cum boost charger is functionally equipped with two operating modes; a float mode and a boost mod

In float cum boost chargers, the battery is charged faster during the boost mode to ensure that the DC current is available in case the load needs supply from the battery. Float cum boost chargers are basically used for charging batteries at substations, powerhouse protection circuits, and telecom exchanges to ensure a continuous supply of power.

Types of Products

SMPS (Switched Mode Power Supply)

DC-DC Convertors

AC UPS & Invertors

ACDB

DCDB

SMPS Based Battery Charger

Madular Based Battery Charger

Lenear Based Battery Charger

Thyristor Based Battery Charger

LT Pannels & HT Pannels

Relay Pannels

Oparationg AC Input Voltage

415V or 400V or 380V or 230V or as specified by Customer with +/- 10% tolerance 1 Phase or 3 Phase - 3 wire/4 wire, 50 Hz +/- 5% Voltage & Frequency tolerance can be enhanced as per the customer's requireme

DC Output Voltage

12V/24V/48V/110V/220V/360 V or as per customer's requirement

DC Output Current

Up to 300 A

Different Configurations of Battery charger

Float Cum Boost (FCB)

Float and Boost ( FC and BC)

Float and Float Cum Boost charger (FC & FCBC)

Dual Float Cum Boost (DFCBC)

Application/Customer specific requirement

Salient Features

Suitably designed for all types of batteries - Lead acid (Plante/OPzS/TBS/HR Tubular/AGM VRLA,GEL Tubular) and Ni-Cd

Microprocessor Controlled/Analog Controlled

Soft Start feature

Battery path limiting current

Automatic Float Boost Changeover

Protection against AC phase reversal, single phasing, A.C Under Voltage, Over Voltage, A.C Unbalance

Dropper diode regulator in load path for specific application

Battery charger services encompass a range of offerings aimed at maintaining, repairing, and optimizing battery charging systems. These services may include:

Installation: Professional installation of battery charging systems, ensuring proper setup and compatibility with the batteries being charged.

Maintenance: Regular inspection and upkeep of battery chargers to identify and address issues before they escalate, ensuring optimal performance and longevity.

Repair: Diagnosing and fixing malfunctions or damage in battery chargers to restore functionality and prevent further problems.

Calibration: Adjusting charging parameters to optimize performance and ensure accurate charging levels for different types of batteries.

Upgrades: Installing upgrades or updates to battery chargers to enhance efficiency, safety, or compatibility with newer battery technologies.

Testing: Conducting tests to assess the charging performance of battery chargers and ensure they meet safety and quality standards.

Consultation: Providing expert advice on selecting the right battery charger for specific applications, as well as offering guidance on usage, maintenance, and safety practices.

Brochure

"Welcome to the future of power management. Our industrial battery chargers are designed to optimize efficiency, reliability, and performance for your critical operations. With cutting-edge technology and robust engineering, our chargers ensure uninterrupted power supply, prolong battery life, and minimize downtime. Explore our range of solutions tailored to meet the demands of diverse industries, and experience the difference in power management excellence."
